Comparative Analysis of Waste Water Treatment Plants (WWTP) VS. Biodigesters

Many times Bio digesters are confused with Sewage treatment & recycling plants, here is a brief comparative analysis.

WASTE WATER TREATMENT PLANT (WWTP) – Sequential Batch reactor (SBR) BIODIGESTER
Definition
The SBR waste water treatment process is an activated sludge process in which the sewage after pretreatment is introduced into a Reaction Tank (or SBR Tank), one batch at a time. Wastewater treatment is achieved by a timed sequence of operations which occur in the same SBR Tank, consisting of filling, reaction (aeration), settling, decanting, idling, and sludge wasting. Clean treated water is produced.
A biodigester is like a mechanical stomach. It is fed with organic material, which is broken down (decomposed) by micro-organisms (bacteria) is an oxygen-free (anaerobic) environment to produce a renewable energy called biogas (methane and carbon dioxide) and other material that is mainly used as fertilizer.
How does it work?

The various stages in the sequence are as follows:
Stage 1: Filling The SBR Tank is filled with the influent wastewater. In order to maintain suitable F/M (food to microorganism) ratios
Stage 2: Reaction This stage involves the utilization of biochemical oxygen demand (BOD) and ammonia nitrogen by microorganisms. The waste water is aerated with a blower t provide oxygen for microorganismas as well as kill odor Stage 3: Settling Sludge settles leaving clear, treated effluent above the sludge blanket. Stage 4: Discharging Clean treated effluent is removed from the tank through the discharge air sunction pipe without disturbing the settled sludge.
Stage 5: Sluge wasting & Idling Excess sludge is pumped back to pretreatment and system waits idle until it is time to commence a new cycle with the filling stage.

The feed stock is shredded with water to a slurry and added to the digester on a regular basis. Within the closed tank methanisation occurs. Each day, the waste to be added needs to be mixed with water and/or ground to a liquid state. Kitchen scraps, such as banana and orange peels need to be ground in smaller parts which can be time consuming. Each day, the biodigester effluent needs to be removed manually from the effluent tank.The Methane gas produced too has to be released real time for consumption.
Oxygen
This process requires Oxygen as it is aerobic. Usually provided by a blower
Anaerobic process that does not require oxygen
Raw material
Black (from the toilets) & grey water (from kitchens, bathrooms, house cleaning)
Organic solids & black water only
Products of the process
Clean treated water reusable for secondary purposes e.g. irrigation & flushing toilets. Sludge that requires to be exhausted after five years and can be used as fertilizer
Ethane gas. Slurry that has to be removed daily and can be used as fertiliser
Temperature
Operate effectively in temperatures as low as 10 degrees
Operate effectively between 20 to 40 degrees
Footprint
Not so much space required, and the system is underground
Requires large space to manage all the processes and by products
